| Category | Specification |
|---|---|
| Engine | FM 2.6 CR ED |
| Emission | BS-VI Stage 2 |
| Type | 4 Cylinder, Common Rail, DI TCIC |
| Bore x Stroke (mm) | 90.9 x 100 |
| Displacement | 2596 cc |
| Max Output | 85 kW (114 hp) @ 2950 rpm |
| Max Torque | 350 Nm @ 1400-2200 rpm |
| TRANSMISSION | |
| Type | Manual, Gear Lock Synchromesh on forward gears |
| Model | G32-5 |
| No. of Gears | 5 Forward + 1 Reverse |
| BODY | |
| Type | Monocoque construction |
| SUSPENSION | |
| Front & Rear | Spring Semi elliptical |
| Anti roll bar | Yes |
| Shock absorbers | Hydraulic telescopic double acting at front and rear |
| STEERING | |
| Type | Power Steering |
| BRAKES | |
| Type | Dual circuit, hydraulic, vacuum assisted, auto slack adjuster, ABS with EBD |
| Auto Slack Adjuster | Yes |
| Front | Disc |
| Rear | Drum |
| Parking | Mechanical acting on rear wheel |
| WHEELS & TYRES | |
| Size | 215/75 R 15 |
| Tyre Type | Radial with Tube/Tubeless / (4+1) |
| DIMENSIONS (mm) | |
| Wheel Base | 3700 |
| Overall Length | 6265 |
| Overall Width | 1900 |
| Overall Height | 2550 |
| Ground Clearance | 200 |
| WEIGHT (kg) | |
| Maximum GVW | 4300 |
| CAPACITY | |
| Fuel Tank | 70 Litres |
| SEATING CAPACITY | |
| Seating Capacity | 17+D/12+D |
| Seating Type | Recliner/ High back/ St |
FORCE BUS
MAX TORQUE 350 NM
17 SEATER
5 SPEED (5F+1R)
MAX TORQUE 350 NM
